WiMi4000

Low Latency (80ms) Full HD & Streaming by H.264 Encoder

Characteristics of WiMi4000

Full HD sender (Ethernet/Internet)
H.264 (MPEG-4 Parts10: AVC)
Baseline Profile with level 4.2
Low latency ,end-to-end (80~100ms), H.264 engine
Transport 1080p60 full HD over Ethernet/Internet
Video formats of DTV and VESA spec.
Linear-PCM and compressed audio
Maximum encoding rate of 15Mbps
Save bandwidth cost with Multicasting
Multicasting: No limits on the number of receivers when the multicasting
network is configured
Relay Streaming server on the receiver
Live streaming from Camera, CCTV or PC over Internet
Full HD live streaming server (Transmitter & Receiver)
RTSP streaming server (RTP/UDP)
MPEG-2 TS/UDP streaming
Easy control with Web User Interface
HD contents display for digital signage
Applications
Digital Signage
Control Room
Medical Imaging
Full HD Video TX
Low-cost Full HD Encoder
Full HD Live Streaming
RTSP/MPEG-2 TS Server
Education/Multi-Vision

Interfaces of WiMi4000

Video Interfaces
2 x HDMI (DVI): up to 1080p60, HDMI v1.3 compatible
PC (HD-15): VESA formats up to 1920 x 1080p60
Composite video: 720 x 480i60 and 720 x 576i50
Network Interfaces
10/100 BASE-TX, Cat.5e UTP cable
Audio Interfaces
Digital: Linear PCM (44.1kHz/48kHz) or compressed 5.1
Analog: Stereo, 48kHz 16-bit linear PCM, G.711
Jack: RCA stereo & mini stereo phone

Video Specifications of WiMi4000

Audio Interfaces

Audio Interfaces
RESOLUTIONS TRANSMITTER RECEIVER
HDMI PC CVBS HDMI COMP CVBS
640x480p60/70/85 O O X O X X
800x600p60/70/85 O O X O X X
1024x768p60/70/85 O O X O X X
1152x864p60/70/85 O O X O X X
1280x800p60 O O X O X X
1280x960p60/70/85 O O X O X X
1280x1024p60 O O X O X X
1360x768p60 O O X O X X
1440x900p60 O X X O X X
1600x1200RP60 O O X O X X
1600x900p60 O X X O X X
1680x1050p60 O O X O X X
720x480i60(NTSC) O O O O O O
720x576i50(PAL) O O O O O O
720x480p60 O O X O O X
720x576p50 O O X O O X
1280x720p50/60 O O X O O X
1920x1080i50/60 O O X O O X
1920x1080p24 O O X O X X
1920x1080p25/30 O X X O X X
1920x1080p50/60 O O X O X X
